DMS-20LCD-4/20 Series
4-20mA Input Loop-Powered Ultra-Low 1.8V Loop Drop
3? Digit LCD Display Process Monitors
TRANSMITTER &
PROGRAMMABLE LOGIC CONTROLLER
?
SIGNAL CONDITIONER
+
–
DMS-20LCD-4/20
GAIN
+
(TB1-1)
+
R7
TRANSDUCER
INPUT
4-20mA
+
A/D
Vsig
R3
–
4-20mA
(TB1-2)
–
–
ZERO
+24V
+24Vdc
+
? Shown for illustrative purposes only, may not be present in all applications
SUPPLY
–
Figure 2. Typical DMS-20LCD-4/20 Connection Diagram
BEZEL INSTALLATION AND RECOMMENDED DRILL AND PANEL CUTOUT
FRONT VIEW
#2-56 INSERT
0.156 (3.96) DEEP
1.826 (46.38)
0.187
(4.75)
1.280
(32.51)
BEZEL INSTALLATION
BEZEL
PANEL
RECOMMENDED DRILL AND PANEL CUTOUT DIMENSIONS
INTERNAL CORNER RADII:
1.07
(27.18)
0.032 (0.81) MAX.
0.838
(21.29)
RETAINING CLIP INSTALLATION
1.336 (33.93)
1.626 (41.30)
0.093 (2.362) DIAMETER (4 REQUIRED)
ONLY WHEN USING OPTIONAL BEZEL ASSEMBLY
0.145
(3.68)
0.116
(2.95)
PANEL
www.murata-ps.com/dpm
Technical enquiries email: sales@murata-ps.com, tel: +1 508 339 3000
MPM_DMS20LCD-420.B03 Page 5 of 6
